API 675 Electric Pumps

The API 675 series offers a range of hydraulic membrane dosing pumps with stroke lengths of 15 or 20 mm. This series provides capacities from 7 to 1,506 liters/hour in the pressure range of 100 – 7 bar, enriched with features such as Full-motion Drive and automatic air discharge. In addition, it attracts attention with its compliance with API 675 standards.

Model DO-EPM

• Design and manufactured for variety kinds of chemicals.

• For hazardous area applications

• Electric Motor Driven pumps with turndown ratio 1/10 as per API 675

• Double Teflon Diaphragm

• Rupture Detection Pressure Gauge / Pressure Transmitter

• Cast Iron & Cast Steel Body

• SS316L Pump Head

• 0.5-110.2 LPH Flowrate

• 137.9-27.6 bar Max working allowable pressure

• Auto / Manual Stroke Control

• 230/380/400/415/440 VAC

• External control via 4 – 20 mA or HAART Communication

Model DO-EPS

• Design and manufactured for variety kinds of chemicals.

• For hazardous area applications

• Electric Motor Driven pumps with turndown ratio 1/10 as per API 675

• Double Teflon Diaphragm

• Rupture Detection Pressure Gauge / Pressure Transmitter

• Cast Iron & Cast Steel Body

• SS316L Pump head

• 5.1-149.5 LPH Flowrate

• 250.4-50.2 bar Max working allowable pressure

• Auto / Manual Stroke Control

• 230/380/400/415/440 VAC

• External control via 4 – 20 mA or HAART Communication

• Multi-head Pump option

Model DO-EPX

• Design and manufactured for variety kinds of chemicals.

• For hazardous area applications

• Electric Motor Driven pumps with turndown ratio 1/10 as per API 675

• Double Teflon / Stainless steel diaphragm

• Rupture Detection Pressure Gauge / Pressure Transmitter

• Cast Iron & Cast Steel Body

• SS316L Pump head

• 1.2 – 1809.8 LPH Flowrate

• 550.4 – 6.2 bar Max working allowable pressure

• Auto / Manual Stroke Control

• 230/380/400/415/440 VAC

• External control via 4 – 20 mA or HAART Communication

• Multi-head Pump option
